Mobile Cone Crusher

Mobile cone crusher is usually equipped with cone crusher and vibrating screen. It is suitable for two-stage and three-stage crushing. The main cone crusher system can be freely matched with symons cone crusher and hydro cone crusher.

Mobile Cone Crusher

Processing Materials of Mobile Cone Crusher

It is widely used for secondary fine crushing of granite, river stone, quarry stone, rock, boulder, gravel, aggregate, basalt, limestone, gold ore, iron ore, chrome ore, etc. Adjustable final size meeting different needs. Following is common final output size.

Working Principle of Mobile Cone Crusher

The materials are uniformly transported into the crusher by the feeder. After the secondary fine crushing by the cone crusher, the closed circuit system is formed through the circular vibrating screen to realize the circular crushing of the materials. The materials after crushing will be conveyed out by belt conveyor, thus forming continuous crushing operation.

undefined

Advantages of Mobile Cone Crusher

undefined

Unit integration

It can be directly operated, eliminating tedious infrastructure installation and labor time consumption

Hydraulic control system

The feeding guard is hydraulically raised and lowered, which is convenient for loading and unloading, convenient for fixing, stable and reliable.

Intelligent operation

One person can operate, the work is more stable, the overall output is increased, and the finished product has complete specifications and good particle shape.

Dual power drive

Switch freely between electtic power and diesel, keeping in good condition anytime and anywhere.

Hot Issues of Mobile Cone Crusher

undefined

Hot Sale Types of Mobile Cone Crusher

Mobile Symons cone crusher, suitable for small and medium crushing needs.

Mobile hydro cone crusher, usually for large scale production scale.

Hot Sale Capacity of Mobile Cone Crusher

80-100t/h, 120-150t/h, etc, usually for small production scale, with low costs.

150-200t/h, 230-250t/h, 250-300t/h, etc, usually for medium and large production scale.

The estimated price of the service

Price range is about 4000-500,000 dollars. Click for specific price.

Get quotes

Technical parameters

Wheel-type Mobile Cone Crusher

Tracked Cone Crusher

Model FTM3S185GYS300 FTM3S216GYS400 FTM3S216HP300
Transportation length(mm) 14500 15000 16000
Transportation Width(mm) 3000 3000 4550
Transportation Height(mm) 4400 4500 4600
Maximum Length(mm) 17000 16000 17000
Maximum Width(mm) 3400 3900 6900
Maximum Height(mm) 5800 6500 4700
Weight(t) 34.5 49.5 41
Tire Configuration Dualaxial Triaxial Triaxial
Cone crusher GYS300 GYS400 HP300
Discharging belt Conveyor B650×15M×2 B800×15M×2 B800×15M×2
Return belt conveyor B650×14M B800×14M B800×16M
CONveyor Belt For Final Products B500×15M B800×6M B650×15M×2
Under Virbrating Screen B800×7M B800×8M B800×9M
Vibrating Screen 3YK1854 3YK2160 3YK2160

Model WT160SC and WT250SC

Model WT160SC WT250SC
Dimensions of Transmission Devices Length 16800mm 19500mm
Width 3500mm 3600mm
Height 3700mm 3800mm
Weight 50t 60t
Belt Conveyor Hopper Volume 3m³ 3m³
Loading Height 2600m 2600m
Loading Width 1900mm 1900mm
Dimensions
(Width×Length)
1000×6300mm 1000×6300mm
Crusher Model SC160 HP400
Inlet Dimensions 75-360mm 75-450mm
Max.Feeding Size 360mm 450mm
Min. Discharging Size 8-25mm 8-35mm
Main Belt Conveyor Dimensions
(Width×Length)
1000×9000mm 1000×11000mm
Dumping Height 3100mm 3490mm
Secondary Screen Dumping Height 4200mm 4400mm
Model HX1536 HX1536
Sieve Dimensions 1500×3600mm 1500×3600mm
Belt Conveyors at the Bottom Dimensions
(Width×Length)
1000×5600mm 1000×6500mm
Dumping Height 3020mm 3020mm
Belt Conveyors to the Sieve Dimensions
(Width×Length)
650×2100mm 650×2100mm
Dumping Height 1370mm 1370mm
Belt Conveyors for Discharging Material Dimensions
(Width×Length)
650×10000mm 650×10000mm
Dumping Height 4200mm 4200mm
Diesel Engine Power 96kw 132kw
Manufacturer Carter Perkins Carter Perkins
The Main Machine Power 207.12kw 362.12kw
Ways of Controlling Wired/Wireless (optional) Wired/Wireless (optional)

Model WT300HPM and WT400HPM

Model WT300HPM WT400HPM
Dimensions of Transmission Devices Length 19000mm 19500mm
Width 3900mm 3900mm
Height 3800mm 3800mm
Weight 55t 65t
Belt Conveyor Hopper Volume 3m³ 3m³
Loading Height 2600m 2800m
Loading Width 1900mm 1900mm
Dimensions
(Width×Length)
1000×6300mm 1200×6500mm
Crusher Model HP300 HP400
Inlet Dimensions 60-200mm 68-280mm
Max.Feeding Size 200mm 280mm
Min. Discharging Size 8-45mm 8-51mm
Main Belt Conveyor Dimensions
(Width×Length)
1000×10000mm 1000×11000mm
Dumping Height 3490mm 3690mm
Secondary Screen Dumping Height 4400mm 4400mm
Model HX1536 HX1536
Sieve Dimensions 1500×3600mm 1500×3600mm
Belt Conveyors at the Bottom Dimensions
(Width×Length)
1000×5600mm 1000×6500mm
Dumping Height 3020mm 3300mm
Belt Conveyors to the Sieve Dimensions
(Width×Length)
650×2100mm 650×2100mm
Dumping Height 1370mm 1370mm
Belt Conveyors for Discharging Material Dimensions
(Width×Length)
650×11000mm 650×11000mm
Dumping Height 4400mm 4400mm
Diesel Engine Power 106kw 132kw
Manufacturer Carter Perkins Carter Perkins
The Main Machine Power 267.12kw 362.12kw
Ways of Controlling Wired/Wireless (optional) Wired/Wireless (optional)
